Puma IV-60 LX powered by a digitally controlled servo system. The Puma IV features a standard Accu-Aligning System(AAS II) to guarantee precise contour cutting by detecting the registration marks on digitally produced images.

Puma IV incorporates a precision electro-mechanical design, which ensures an extremely accurate cutting capability. The state-of-the-art, closed-loop, high-speed digital servo drive system provides smooth, quiet, and fast operation.Recommended to cutting flex and flock films and occasional cutting magnetic sheets to the thickness 0,8 mm.

Technical data:

• Max. Cutting Width: 600 mm
• Max. Media Loading Width: 719 mm
• Acceptable Material Thickness: 0.8 mm
• Drive: DC Servo Control
• Cutting Force: 500 g
• Max. Cutting Speed (Diagonal): 1020 mm /sec
• Software Resolution: 0.025 mm
• Number of Pinch Rollers: 2
• Memory Size: 32 MB(AAS) / 16 MB
• Interfaces: USB 2.0 / Serial (RS-232C)/ Ethernet
• Type of Command: HP-GL, HP-GL/2
• Configurable Origin: yes
• Control Panel: LCM (20 digits X 2 lines), 14 Keys , 1 power LED

The standard equipment:

• stand
• power wire
• USB wire
• handle with knife
• reserve knife
• knife for cut off foil
• tweezers
• reserve teflon strip
• Polish and English manual
• "Notification" with Voucher Code to register GreatCut and link to GCC site, where you can download printer drivers to CorelDraw and the latest GreatCut
• compatible with Windows 7 / 8 / 10
